PP/PE Film Washing Line

It is applicable to agricultural film, market film, municipal solid waste separation film, woven bag, ton bag, etc.
Quantity:


It is applicable to agricultural film, market film, municipal solid waste separation film, woven bag, ton bag, etc.


images_02






· Suitable for all kinds of films and woven bags with a sediment content of up to 80%.


· Using circulating water to ensure the washing effect while controlling the water flow and evaporation.


· The core part of the pretreatment module adopts a wear-resistant design to ensure the continuous operation of the system for a long time.


· The pre-crushing and pre-washing system efficiently removes most of the impurities such as sediment, protects subsequent equipment, and greatly increases the service life of the crushing and washing system.


· The crushing system is designed specifically, the size of the crushed film is about 50-60mm and we using durable D-2 crusher blades.


· The high-speed centrifugal de-watering machine applies corresponding blade strikes to different materials at a suitable rotation speed to achieve the ideal washing effect.


· The PP PE film washing tank is designed for strong pressure underwater washing to remove residual impurities; the claw-type uniform speed discharge ensures uniform discharge while controlling the water content, providing a process basis for the dehydration module.


·The film drying technology of centrifugal dewatering, screw squeezing and high temperature hot air strictly controls the moisture content of the finished product within 5%, which is suitable for high-quality granulation requirements.


· The whole PP PE film washing line is automatically controlled, and the units of the system are associated with each other. It has a pre-judgment function for possible abnormal situations to ensure the safety of the system.

Corresponding granulation system can be equipped according to production requirements.


PPPE-Film-Washing-Line




Model

BXC-300

BXC-500

BXC-1000

BXC-2000

Output(KG/H)



300

500

1000

2000

Installed Power(KW)



130-160

210-260

300-350

400-460

Water Consumption(T/H)



2-3

4-6

7-10

10-15

Labor Requirements



2-3

2-3

3-5

4-6
